NE30 Engineering Parameter Diagram [Unit: mm]
Motor Operating Parameters
Motor Type:
Brushless Servo Motor
Power:
113 W
Rated Voltage:
48 VDC
Rated Speed:
8000 rpm
No-Load Speed:
10650 rpm
Rated Torque:
0.135 N·m
Peak Torque:
0.405 N·m
Torque Constant:
0.0348 N·m/A
Phase Current Rating:
16.5 A
Rated Bus Current:
3.0 A
Static Bus Current:
0.08 A
Basic Parameters
Voltage Range:
24-48 VDC
Resolution:
16384 (14-bit) Step/turn
Diameter:
Φ42 mm
Length:
21 mm
Weight:
95g
Rotation Angle:
> 360.0°
Noise Level:
≤ 70 dB(A)
Temperature Range:
-20°C to +80°C
Rotor Moment of Inertia:
99.35 g·cm²
Rated Static Load:
140 N
