Atom Series
Compact Brushless Motors
For Robotics Fields, Underwater Unmanned Ships, Professional PTZ, AGV Logistics, Laser Printers, and 3D Printers.
Flat-design Brushless DC motors with high torque density and 14-bit encoders, designed for PTZ cameras, 3D printers, AGV wheels, laser modules, and underwater robotics. A quiet and reliable option for compact motion control and precision gimbals.
ELECTRON EL20
Brushless Servo Motor
Power: 36 W; Diameter: Ø29 mm; Length: 13.5 mm; Weight: 50g
Rated Voltage: 42VDC
Resolution: 16384 (14-bit) Step/turn
Torque: 0.023 N·m (rated), 0.069 N·m
Up to 6,000 rpm (no-load), 4,000 rpm (rated)
NUCLEUS NU80
Brushless Servo Motor
Power: 500 W; Diameter: Ø29 mm; Length: 13.5 mm; Weight: 50g
Rated Voltage: 42VDC
Resolution: 16384 (14-bit) Step/turn
Torque: 1.1 N·m (rated), 3.3 N·m
Up to 2,200 rpm (no-load), 1,500 rpm (rated)
NEUTRON NE30
Brushless Servo Motor
Power: 200 W; Diameter: Ø42 mm; Length: 21 mm; Weight: 150g
Rated Voltage: 42VDC
Resolution: 16384 (14-bit) Step/turn
Torque: 0.192 N·m (rated), 0.575 N·m
Up to 6,000 rpm (no-load), 4,000 rpm (rated)
PROTON PR60
Brushless Servo Motor
Power: 500 W; Diameter: Ø67 mm; Length: 23 mm; Weight: 300g
Rated Voltage: 42VDC
Resolution: 16384 (14-bit) Step/turn
Torque: 0.66 N·m (rated), 2 N·m
Up to 4,200 rpm (no-load), 3,000 rpm (rated)
