PR60 Engineering Parameter Diagram [Unit: mm]
Motor Operating Parameters
Motor Type:
Brushless Servo Motor
Power:
326 W
Rated Voltage:
48 VDC
Rated Speed:
5000 rpm
No-Load Speed:
6305 rpm
Rated Torque:
0.62 N·m
Peak Torque:
1.86 N·m
Torque Constant:
0.0606 N·m/A
Phase Current Rating:
33 A
Rated Bus Current:
8 A
Static Bus Current:
0.08 A
Basic Parameters
Voltage Range:
24-48 VDC
Resolution:
16384 (14-bit) Step/turn
Diameter:
Φ67 mm
Length:
23 mm
Weight:
221g
Rotation Angle:
> 360.0°
Noise Level:
≤ 70 dB(A)
Temperature Range:
-20°C to +80°C
Rotor Moment of Inertia:
99.35 g·cm²
Rated Static Load:
140 N
