NU80 Engineering Parameter Diagram [Unit: mm]
Motor Operating Parameters
Motor Type:
Brushless Servo Motor
Power:
213 W
Rated Voltage:
42 VDC
Rated Speed:
2000 rpm
No-Load Speed:
3120 rpm
Rated Torque:
1.02 N·m
Peak Torque:
3.06 N·m
Torque Constant:
0.1 N·m/A
Phase Current Rating:
33 A
Rated Bus Current:
6 A
Static Bus Current:
0.08 A
Basic Parameters
Voltage Range:
24-45 VDC
Resolution:
16384 (14-bit) Step/turn
Diameter:
Φ86.8 mm
Length:
21 mm
Weight:
450g
Rotation Angle:
> 360.0°
Noise Level:
≤ 70 dB(A)
Temperature Range:
-20°C to +80°C
Rotor Moment of Inertia:
22.5254 g·cm²
Rated Static Load:
40 N
